LKAD035F 29W 20-42V 700mA slim led driver

Features

• 200-240Vac(50/60Hz) Input
• Hight efficiency,hight PF,good steady;
• Adopting the original constant voltage and current isolation scheme of the United States.

• independent, ClassⅡconstant current type;
• short circuit/over load/over current/ over temperature protection;
• 100% full load burn-in test;
• degree of protection IP20;
• suitable for LED lighting,ceiling light,down light and panel light;
• 5 years warranty.

---

More Details

Model		LKAD035F
輸入Input	輸入電壓范圍/Input Voltage range	120-240V
	頻率/Frequency	50/60hz
	諧波/THD	<10%
	功率因數/Power factor	0.97%/230V
	輸入電流 Input current（mA)	130MA
	待機功耗 stand_by power	≤0.5s/230VAC
	浪涌電流 Inrush Current(Max.)	≤30A@230VAC
	漏電流 Leakage Current	<1MA/240V
輸出Output	額定電壓/Rated voltage	40V
	空載電壓/No-load Voltage	42V
	工作電壓范圍/working voltage range	20-42V
	可選擇電流規格/selectable current specs	700MA±20MA
	電壓精度/Voltage accuracy	(+/-)3%
	額定功率/Rated power	28W
	開機延時/Setup Time	≤0.5s/230VAC
	輸出線性調整率Output Line Regulation	±5%
	溫度漂移temperature drift	±10%

保護特性	開路保護Output open circuit protection	有/Enable
	短路保護Short Circuit Protection	打嗝模式/Hiccup mode
使用環境Environment Requirements	工作溫度/濕度要求Operating Temp./RH	-30～+45℃/20～95%
	儲存溫度,濕度要求Storage Temp./RH	-40～+80℃/10～95%
安全和電磁兼容 Safety & EMC	認證編號/Certificate	符合CE
	耐壓 withstand voltage	4KV
	絕緣阻抗insulation resistance	500V>100M
	浪涌等級EMS immunity	IEC6100-4-5(L-N:1KV)
	安規標準Safety standard	EN61347,GB19510
	電磁干擾electromagnetic interference	EN55015,EN61000-3-2
	電磁抗干擾Electromagnetic Susceptibility	EN61000-4-2.3.4.5.6.8.11.EN61547
其他Others	IP等級說明 IP level description	IP20
	質保說明Warranty instructions	3年/3 years
	尺寸/Size	L166mm * W50mm * H11mm
