| Authentication: |
| Model | LKAD016D-C | |
| 輸入 Input | 輸入電壓范圍/Input Voltage ra | 120-277V |
| 頻率/Frequency | 50/60hz | |
| 諧波/THD | ≤10% | |
| 功率因數/Power factor | 0.95/240VAC | |
| 輸入電流 Input current（mA) | 80MA/240V | |
| 待機功耗 stand_by power | ≦1W | |
| 浪涌電流 Inrush Current(Max.) | ≤40A@240VAC | |
| 漏電流 Leakage Current | <1MA/240V | |
| 輸出 Output | 額定電壓/Rated voltage | 45V |
| 空載電壓/No-load Voltage | ≦49V | |
| 工作電壓范圍/working voltage | 0-45V | |
| 可選擇電流規格/selectable cur | r 350MA±10MA | |
| 電流精度/Current precision | (+/-)3% | |
| 額定功率/Rated power | 35W | |
| 開機延時/Setup Time | ≤0.5s/230VAC | |
| 輸出線性調整率Output Line Reg | u ±5% | |
| 溫度漂移temperature drift |
±10% Page 1 of 4 |
