LKAD058D-C 71W 2-42V 1500mA 0-10V Dimming LED drivers
  • LKAD058D-C 71W 2-42V 1500mA 0-10V Dimming LED drivers

LKAD058D-C 71W 2-42V 1500mA 0-10V Dimming LED drivers

  • Product model : LKAD058D-C
  • Input voltage : 200-240Vac
  • Output power(W) : 71W
  • Output voltage : 45-85Vdc/2-42Vdc
  • Output current(A) : 375-750mA/750-1500mA
  • Light adjustment : 0-10V Dimming
  • Size(MM) : 135x45x25mm
Authentication:
Skype
  • Product Detail
  • Send Inquiry
  • Download

LKAD058D-C TUV CE SAA approved 71W 2-42V 1500mA 0-10V Dimming LED drivers


Features

  • 100-240VAC(50/60Hz) Input
  • Isolated high PF no stroboscopic scheme,
  • High efficiency, high power factor, high stability, high light ratio
  • Flicker free
  • Short circuit,over voltage,over current and over temperature protection;
  • Remote control performance is stable, any angle direction can be controlled. The control distance can be up to 35 meters in open field and 15-20 meters in places with obstacles.
  • independent, ClassⅡ constant current type;
  • degree of protection IP20;
  • By adopting the control scheme of single chip microcomputer with independent intellectual property rights, 0.1% dimming resolution can be achieved Lighting,ceiling light,down light and panel light;
  • 3 years warranty.

More Details

Model LKAD058D-C
輸入             Input 輸入電壓范圍/Input Voltage range 200-240V
頻率/Frequency 50/60hz
諧波/THD ≤10%/230VAC
功率因數/Power factor 0.97/230VAC
輸入電流 Input current（mA) 329MA/230V
待機功耗 stand_by power ≦2W
浪涌電流 Inrush Current(Max.) ≤60A@230VAC
漏電流 Leakage Current <1MA/230V
輸出      Output 額定電壓/Rated voltage 85V
空載電壓/No-load Voltage ≦95V
工作電壓范圍/working voltage range 0-85V
可選擇電流規格/selectable current specs 750MA±22MA
電流精度/Current precision (+/-)3%
額定功率/Rated power 75W
開機延時/Setup Time ≤0.55s/230VAC
輸出線性調整率Output Line Regulation ±5%
溫度漂移temperature drift ±10%
保護特性 開路保護Output open circuit protection 有/Enable
短路保護Short Circuit Protection 打嗝模式/Hiccup mode
使用環境    Environment Requirements 工作溫度/濕度要求                    Operating Temp./RH -30～+45℃/20～95%
儲存溫度,濕度要求                   Storage Temp./RH  -40～+80℃/10～95%
安全和電磁兼容 Safety & EMC 認證編號/Certificate 符合CE/ meet CE
耐壓 withstand voltage 3750VAC/60S
絕緣阻抗insulation resistance 500V>100M
浪涌等級EMS immunity IEC6100-4-5(L-N:1KV)
安規標準Safety standard        IEC61347-2-13   EN6147-2-13
電磁干擾electromagnetic interference                Fcc Part15B
電磁抗干擾Electromagnetic Susceptibility                Fcc Part15B
其他
Others 		IP等級說明 IP level description IP65
質保說明Warranty instructions 3年/3 years
尺寸/Size 155*50*28MM
重量/Netweight 100g
